  • AUDIO XFMR 100K / 1.5K CHAS MNT
  •  140MEX Datasheet
  • Cost
    Reduction
  • Min Order From 1 PCS
  • 365 Days Warranty
  • 12 Hours Quotation
Product Specifications
  • AttributesAttribute Value
  • ManufacturerHammond Manufacturing
  • CategoryTransformers
  • PackagesBulk
  • Standard Quantity1
  • Description100k Impedance Primary Ohms 1.5k Impedance Secondary Ohms 8.13:1 Audio Transformer 20Hz ~ 20kHz Chassis Mount
  • Size / Dimension1.250" Dia (31.75mm)
  • Mounting TypeChassis Mount
  • Termination StyleScrew Terminal
  • Turns Ratio - Primary:Secondary8.13:1
  • Insertion Loss1.2dB Typ
  • Frequency Range20Hz ~ 20kHz
  • Voltage - Isolation500Vrms
  • Return Loss30dB Typ
  • Height - Seated (Max)1.000" (25.40mm)
  • Impedance - Primary (Ohms)100k
  • Impedance - Secondary (Ohms)1.5k
  • DC Resistance (DCR) - Primary5.43kOhm
  • DC Resistance (DCR) - Secondary159Ohm
  • Frequency Response±1dB
  • Power Level10dB
