Product Specifications
  • AttributesAttribute Value
  • ManufacturerMolex
  • CategoryConnectors, Interconnects
  • PackagesBulk
  • Standard Quantity1
  • DescriptionConnector Header Through Hole 20 position 0.100" (2.54mm)
  • Connector TypeHeader
  • Mounting TypeThrough Hole
  • Number of Positions20
  • Number of Rows1
  • StyleBoard to Board or Cable
  • ApplicationsAutomotive, General Purpose, Medical, Telecommunications
  • Contact TypeMale Pin
  • Fastening TypeFriction Lock
  • Number of Positions LoadedAll
  • TerminationSolder
  • Material Flammability RatingUL94 V-0
  • Contact MaterialBrass
  • Insulation ColorWhite
  • Pitch - Mating0.100" (2.54mm)
  • Contact Finish - MatingTin
  • Contact Finish Thickness - Mating100.0µin (2.54µm)
  • Contact Finish - PostTin
  • Contact Finish Thickness - Post100.0µin (2.54µm)
  • Contact ShapeSquare
  • Contact Length - Post0.140" (3.56mm)
  • Insulation Height0.322" (8.18mm)
  • ShroudingShrouded - 1 Wall
  • Overall Contact Length0.560" (14.22mm)
  • Insulation MaterialPolyamide (PA), Nylon
  • Contact Length - Mating0.295" (7.49mm)

VIEW ALL

Quality and Reliability

We supply 100% original and brand-new 0022232201 from Molex only.

Hard Find Electronics Tech Limited is committed to achieving the highest levels of quality to meet and exceed customer requirements. We have built a network of trusted suppliers and assembled a team of experienced professionals to serve our customers better. Our rigorous 3-step quality control process ensures that you receive the best possible service and products. All components supplied by us come with a 365-day quality warranty, guaranteeing your satisfaction and confidence in our products.

Order Guide
  • RFQ
    Source at least two reliable suppliers
  • QUOTE
    Information checking available/price/condition
  • QC PROCESS
    3-Step Quality Control and Professional Third-Party Test
  • SHIPMENT
    FedEx, DHL, UPS, TNT
In Stock: 9,826
Please send an RFQ for instant price and inventory.
 Fast Shipping

QUANTITY

Multiples of 1
