• Sanyo Semiconductor/onsemi
• NTD110N02RT4
• Discrete Semiconductor Products
• MOSFET N-CH 24V 12.5A/110A DPAK
•  NTD110N02RT4 Datasheet
•

• Cost
  Reduction
• Min Order From 1 PCS
• 365 Days Warranty
• 12 Hours Quotation

• AttributesAttribute Value
• ManufacturerSanyo Semiconductor/onsemi
• CategoryDiscrete Semiconductor Products
• PackagesTape & Reel (TR)
• Standard Quantity2500
• DescriptionN-Channel 24 V 12.5A (Ta), 110A (Tc) 1.5W (Ta), 110W (Tc) Surface Mount DPAK
• Package / CaseTO-252-3, DPAK (2 Leads + Tab), SC-63
• Mounting TypeSurface Mount
• Operating Temperature-55°C ~ 175°C (TJ)
• TechnologyMOSFET (Metal Oxide)
• FET TypeN-Channel
• Current - Continuous Drain (Id) @ 25°C12.5A (Ta), 110A (Tc)
• Rds On (Max) @ Id, Vgs4.6mOhm @ 20A, 10V
• Power Dissipation (Max)1.5W (Ta), 110W (Tc)
• Vgs(th) (Max) @ Id2V @ 250µA
• Supplier Device PackageDPAK
• Drive Voltage (Max Rds On, Min Rds On)4.5V, 10V
• Vgs (Max)±20V
• Drain to Source Voltage (Vdss)24 V
• Gate Charge (Qg) (Max) @ Vgs28 nC @ 4.5 V
• Input Capacitance (Ciss) (Max) @ Vds3440 pF @ 20 V
