  • Spang Magnetics (Magnetics)
  • 0P45224EC
  • Magnetics - Transformer, Inductor Components
  • FERRITE CORE EC 4.2UH P
  •  0P45224EC Datasheet
  • Cost Reduction
  • Min Order From 1 PCS
  • 365 Days Warranty
  • 12 Hours Quotation
Product Specifications
  • AttributesAttribute Value
  • ManufacturerSpang Magnetics (Magnetics)
  • CategoryMagnetics - Transformer, Inductor Components
  • PackagesBulk
  • Standard Quantity800
  • DescriptionUncoated P Ferrite Core EC Type 2.055" (52.20mm) Length 0.528" (13.40mm) Width Diameter 0.953" (24.20mm) Height
  • MaterialP
  • Length2.055" (52.20mm)
  • Width0.528" (13.40mm)
  • Height0.953" (24.20mm)
  • Core TypeEC
  • Inductance Factor (Al)4.2 µH
  • Initial Permeability (µi)2500
  • FinishUncoated
  • GapUngapped
  • Effective Length (le) mm105
  • Effective Area (Ae) mm²180
  • Minimum Core Cross Section (Amin) mm²141
  • Effective Magnetic Volume (Ve) mm³18800

VIEW ALL

Quality and Reliability

We supply 100% original and brand-new 0P45224EC from Spang Magnetics (Magnetics) only.

Hard Find Electronics Tech Limited is committed to achieving the highest levels of quality to meet and exceed customer requirements. We have built a network of trusted suppliers and assembled a team of experienced professionals to serve our customers better. Our rigorous 3-step quality control process ensures that you receive the best possible service and products. All components supplied by us come with a 365-day quality warranty, guaranteeing your satisfaction and confidence in our products.

Order Guide
  • RFQ
    Source at least two reliable suppliers
  • QUOTE
    Information checking available/price/condition
  • QC PROCESS
    3-Step Quality Control and Professional Third-Party Test
  • SHIPMENT
    FedEx, DHL, UPS, TNT
In Stock: 793
Please send an RFQ for instant price and inventory.
 Fast Shipping

QUANTITY

Multiples of 1
