Product Specifications
  • AttributesAttribute Value
  • ManufacturerTriad Magnetics
  • CategoryTransformers
  • PackagesBulk
  • Standard Quantity672
  • Description10kCT Impedance Primary Ohms 1.2kCT Impedance Secondary Ohms 2.88:1 Audio Transformer 300Hz ~ 100kHz Through Hole
  • Size / Dimension0.410" L x 0.310" W (10.41mm x 7.87mm)
  • Mounting TypeThrough Hole
  • Operating Temperature-40°C ~ 85°C
  • Termination StylePC Pin
  • Transformer TypeAudio Coupling
  • Turns Ratio - Primary:Secondary2.88:1
  • Frequency Range300Hz ~ 100kHz
  • Voltage - Isolation1000VRMS @ 1 Second
  • Height - Seated (Max)0.465" (11.80mm)
  • Impedance - Primary (Ohms)10kCT
  • Impedance - Secondary (Ohms)1.2kCT
  • DC Resistance (DCR) - Primary1.05kOhm
  • DC Resistance (DCR) - Secondary200Ohm
  • Frequency Response±2dB
  • Power Level50mW
