• Vishay / Siliconix
• IRFD024PBF
• Discrete Semiconductor Products
• MOSFET N-CH 60V 2.5A 4DIP
•  IRFD024PBF Datasheet
•

• Cost
  Reduction
• Min Order From 1 PCS
• 365 Days Warranty
• 12 Hours Quotation

• AttributesAttribute Value
• ManufacturerVishay / Siliconix
• CategoryDiscrete Semiconductor Products
• PackagesBulk
• Standard Quantity2500
• DescriptionN-Channel 60 V 2.5A (Ta) 1.3W (Ta) Through Hole 4-HVMDIP
• Package / Case4-DIP (0.300", 7.62mm)
• Mounting TypeThrough Hole
• Operating Temperature-55°C ~ 175°C (TJ)
• TechnologyMOSFET (Metal Oxide)
• FET TypeN-Channel
• Current - Continuous Drain (Id) @ 25°C2.5A (Ta)
• Rds On (Max) @ Id, Vgs100mOhm @ 1.5A, 10V
• Power Dissipation (Max)1.3W (Ta)
• Vgs(th) (Max) @ Id4V @ 250µA
• Supplier Device Package4-HVMDIP
• Drive Voltage (Max Rds On, Min Rds On)10V
• Vgs (Max)±20V
• Drain to Source Voltage (Vdss)60 V
• Gate Charge (Qg) (Max) @ Vgs25 nC @ 10 V
• Input Capacitance (Ciss) (Max) @ Vds640 pF @ 25 V
