  • TDK EPCOS
  • B65813J0000R030
  • Magnetics - Transformer, Inductor Components
  • FERRITE CORE RM 7.6UH N30 2PCS
  •  B65813J0000R030 Datasheet
  • Cost Reduction
  • Min Order From 1 PCS
  • 365 Days Warranty
  • 12 Hours Quotation
Product Specifications
  • AttributesAttribute Value
  • ManufacturerTDK EPCOS
  • CategoryMagnetics - Transformer, Inductor Components
  • PackagesBox
  • Standard Quantity400
  • DescriptionUncoated N30 Ferrite Core RM Type 1.122" (28.50mm) Length 0.531" (13.50mm) Width Diameter 0.368" (9.35mm) Height
  • Tolerance-20%, +30%
  • MaterialN30
  • Length1.122" (28.50mm)
  • Width0.531" (13.50mm)
  • Height0.368" (9.35mm)
  • Core TypeRM
  • Supplier Device PackageRM 10
  • Inductance Factor (Al)7.6 µH
  • Initial Permeability (µi)4300
  • FinishUncoated
  • GapUngapped
  • Effective Permeability (µe)2720
  • Core Factor (ΣI/A) mm⁻¹0.45
  • Effective Length (le) mm44
  • Effective Area (Ae) mm²98
  • Minimum Core Cross Section (Amin) mm²90
  • Effective Magnetic Volume (Ve) mm³4310
